How to Update a Hill-Rom Connection

Edit the Hill-Rom connection at any time to update the configuration parameters. After saving, you must restart the Vocera Vocera Care Team Sync service to allow changes to take effect.

Use the following steps to update the CTS connection to a Hill-Rom system.

  1. In the CTS Console, click the Connections icon (  ) in the navigation bar on the left.

    The Connections screen appears.

  2. Click the Edit button to the right of the connection that you want to edit.

    The Edit HL7 Connection dialog box appears.

  3. Edit any fields that need to be updated.
    See the descriptions of the fields in How to Add a Hill-Rom Connection.
  4. Click Save to record your changes.
    The Edit Hill-Rom Connection dialog box closes, and the connection changes are saved to the database.
  5. Restart the Vocera CTS service.

    Open the Windows Services Control Panel, navigate to the Vocera CTS service, right-click it, and choose Restart.

    The system reads the connection parameters and related information into memory, and any changes that you have made take effect.
